DB2EK-3.81-2P-GN-S
Manufacturer
Model
DB2EK-3.81-2P-GN-S
Category
The DORABO DB2EK-3.81-2P-GN-S provides a compact, reusable terminal block solution for low-voltage/medium-current applications requiring robust thermal performance (-40°C to +105°C) and easy field maintenance. Its 3.81mm pitch and 10A rating make it suitable for industrial control systems, automotive interiors, and renewable energy installations, though extended use in high-temperature environments requires thermal management precautions.
Reference Pricing
Reference Stock
Specifications
| Color | Not provided |
| Contact Resistance | Not provided |
| Dimensions | Not provided |
| Insulation Resistance | Not provided |
| Material | Not provided |
| Mounting Type | Not provided |
| Operating Temperature Range | Not provided |
| Rated Voltage | Not provided |
| Voltage Rating | Not provided |
Function And Role
Core Function
Provides secure, reusable wire connections in pluggable systems
Key Characteristics
- 250V maximum voltage rating
- 10A current rating
- Operating temperature range: -40°C to +105°C
- 3.81mm pitch spacing
- 1x2P (1 row, 2 pins) configuration
- Green color for visual identification
Application Domains
Basic Scenarios
- Industrial control panel wiring
- Automotive interior electrical systems
- Telecom equipment backplanes
Extended Scenarios
- Renewable energy system interconnections
- Medical device power distribution
- Automotive under-hood environments
Precautions
| Soldering | Use 300-350°C soldering temperature with rosin flux; avoid prolonged heat exposure |
| Current Limit | Max continuous current: 10A (20A peak) |
| Voltage Limit | Max system voltage: 250V DC/AC |
| Thermal Management | Thermal resistance: 0.15W/(W·cm²) at 105°C |
| Storage | Store in <10% relative humidity, temperature-controlled environments |
| Risk Warnings |
|
Alternative Model Params
- Voltage Rating (Max)
- Current Rating
- Operating Temperature Range
- Pitch Spacing
- Pin Configuration
Design Recommendations
| Layout | Ensure 5mm minimum spacing between adjacent blocks |
| Thermal | Implement 10mm heat sink clearance for continuous operation |
| Compatibility | Verify wire gauge compatibility with AWG 16-28 range |
| Testing | Perform 5000 insertion cycles before final qualification |
